Shuttle Rotomolding Machine with Automation and water tank making machine

Shuttle Rotomolding Machine with Automation and water tank making machine

Fabricated Shuttle Rotomolding Machine

Gas Heating Shuttle Rotomolding Machine

Adjustable Rotary Moulding Machine

Place of Origin:

CHANGZHOU

Brand Name:

YINGCHUANG

Certification:

CE, ISO9001

Contact Us

Request A Quote
Product Details
Rotating Speed:
Adjustable
Voltage:
220V/380V/440V
Control System:
PLC
Cycle Time:
15-30min
Max Product Volume:
50000L
Operation Mode:
Automatic
After-sales Service Provided:
Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
Applicable Industries:
Manufacturing Plant
Product Description

Product Description:

The oven adopts an inner circular oven structure, which has high space utilization and is more energy-saving.

The oven uses a fabricated structure, an oven is divided into 4 or 5 and 6 pieces of assembly. The heating method adopts the principle of hot gas going up, heating faster, high efficiency, more energy saving. The burner is imported from the Italian Liya Road brand.

The control system uses Siemens S7-1200 network cable communication method to collect data, reduce the problem of conventional lines, the line laying is more beautiful. Low-voltage electrical appliances using Germany Schneider configuration, more stable and durable.

The whole machine is equipped with a remote maintenance module, and the operation of all equipment far away overseas can be viewed through the Internet at the Yingchuang Rotational Plastic Factory. And all motors are equipped with Siemens variable frequency control to improve the service life and age of the motor and reducer, and the gearbox adopts domestic famous brand heavy-duty gearbox.

The operation mode is fool-like operation, simpler. All transmission parts are geared, more stable, efficient, and the service life is longer.

Yingchuang Rotomolding accepts the personal customization and design of all customers, and determines the final requirements of customers according to the needs of customers, so that customers are satisfied, we can rest assured to purchase.

Shuttle Rotomolding Machine with Automation and water tank making machine 0

Features:

  • Product Name: Shuttle Rotomolding Machine
  • After-sales Service Provided: Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
  • Cycle Time: 15-30min
  • Control System: PLC
  • Operation Mode: Automatic
  • Rotary Moulding Machine
  • Rotomolding Equipment
  • Rotomolding Equipment


Technical Parameters:

Item Parameters
Control System PLC
Applicable Industries Manufacturing Plant
Rotating Speed Adjustable
After-sales Service Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
Product Name Shuttle Rotomolding Machine
Voltage 220V/380V/440V
Max Product Volume 50000L
Operation Mode Automatic
Total Power Advisory Service
Cycle Time 15-30min


Model No
Floor Size Biggesttank made
L(m) W(m) H(m) Operation platform
CS-2A-1000 4 2.8 2 × 150L
CS-2A-1600 8 3.6 2.8 × 500L
CS-2A-2000 10 4.6 3.2 × 1000L
CS-2A-2500 12.5 6.2 4 2500L
CS-2A-3000 14 7 4.2 4500L
CS-2A-3500 16.5 8 4.5 7000L
CS-2A-4000 17.5 9 5.2 10000L
CS-2A-4500 19 10 5.9 14000L
CS-2A-5000 21 11 6.5 20000L
CS-2A-5500 23 12 7 25000L
CS-2A-6000 24.5 13 7.2 35000L
CS-2A-6500 27 15 8 40000L
CS-2A-7500 32 17 9.5 50000L
Shuttle Rotomolding Machine with Automation and water tank making machine 0

Applications:

Our machine can be used for a variety of purposes. These can be divided into several classes:
  • Military class: Heat insulation box, Instrument box, Medical box.
  • Automotive class: Tank, car Base, car shell, Automobile tail box, Fender.
  • Clean class: Washing machine, Cleaning machine, Bathtub, Polishing machine.
  • Lining class: Solar crystal liner, Steel pipe lining.
  • Traffic facilities: Barricade, Road Barrier.
  • Water tank, Drums.
  • Public environmental class: Trash, Leisure chair, Flowerpot, mailbox.
  • Toys: Slide, Shopping Cart, Go-Kart, Pets room.
  • Aquatic products: Water platform,kayak, Floating box.


Customization:

  • Brand Name: YINGCHUANG
  • Place of Origin: CHANGZHOU
  • Certification: CE, ISO9001
  • Delivery Time: 30--60 work days
  • Supply Ability: 3-5 machines per month
  • Max Product Volume: 50000L
  • After-sales Service Provided: Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
  • Applicable Industries: Manufacturing Plant
  • Voltage: 220V/380V/440V
  • Rotating Speed: Adjustable
  • Shuttle Rotomolding Machine: rotary moulding machine, Shuttle Rotomolding Machine, rotational molding machine


Packing and Shipping:

The Shuttle Rotomolding Machine will be packaged and shipped in a wooden crate or in a cardboard box. The crate or box will be reinforced with foam to add an extra layer of protection to the machine. All components will be securely fastened to the crate or box using straps, shrink wrap, or other secure fastening materials. The crate or box will be clearly labeled with the product name, weight, and other pertinent information.

The package will be sent via an insured carrier such as FedEx or UPS, with tracking and full insurance. The buyer will be sent the tracking information once the package has been shipped.Shuttle Rotomolding Machine with Automation and water tank making machine 2
