Multi Arms Rotomoulding Machine 17m*11m*53m 220V 380V 440V for produing water tanks

Multi Arms Rotomoulding Machine 17m*11m*53m 220V 380V 440V for produing water tanks

Multi Arms Rotomoulding Machine

Rotomoulding Machine 220V

Multi Arms Rotary Moulding Machine

Place of Origin:

Jiangsu, China

Brand Name:

yingchuang

Certification:

CE, ISO9001

Contact Us

Request A Quote
Product Details
Feature:
Automatic
Power:
Electric
Material:
Plastic
Tank Volume:
2500L, 4500L, 7000L, 10000L, 14000L
Dimension(L*W*H):
1700*1100*5300
Voltage:
220V/380V/440V
Applicable Industries:
Manufacturing Plant
Warranty:
1 Year
Axis:
Bi-Axis
Capacity:
Customized
Color:
Customized
Control System:
PLC
Cooling System:
Air Cooling
Heating System:
Electric Heating
Power Supply:
220V/380V
Product Name:
Bi Axial Rotomoulding Machine
Product Type:
Rotomoulding Machine
Size:
Customized
Speed:
Variable Speed
Weight:
Customized
Product Description

Product Description:

Introducing an advanced machine, that offers maximum reliability and simplicity in use. Ideal for high volume production of a variety of articles of different sizes with similar working cycles, it is equiped with robust construction and requires minimal maintenance. Further customising possibilities include double loading/unloading station, pre-cooling, etc.

The machine also offers many features such as:

  • Fully Automatic Compact for Consistent Quality Product
  • Sturdy Unique Mechanical Design for Trouble-Free Running
  • High Efficient Heating Chamber for The Best Fuel Economy
  • All Electrical/Mechanical Safety Interlock for Safety Working
  • High Efficient LPG/DIESEL Burner for Fuel Economy
  • Specially Design Blowers to Work Under High Temperature
  • Unique Design for Easy Maintenance and Long-Term Performance

The machine can also be equipped with a minimum of 3 or 4 arms that can change station simultaneously and alternate in different phases.

Multi Arms Rotomoulding Machine 17m*11m*53m 220V 380V 440V for produing water tanks 0

Features:

The oven from Yingchuang Rotomolding Equipment Co., Ltd. features a circular structure, ensuring high space utilization rate and energy-saving performance. It is fabricated into 4, 5 or 6 pieces for assembly convenience.

It also adopts the hot-gas-up principle for heating, for faster, more efficient and more energy-saving performance. The imported Italian Liya Road brand burner adds to the safety.

In addition, the control system of Siemens S7-1200 uses network cable communication to collect data which reduces the potential problem of conventional lines and makes the layout more beautiful.

Lastly, Yingchuang Rotomolding Equipment Co., Ltd. offers personal customization and design in order to meet the customers' satisfaction. They will assess customers' needs and determine the best solution.



Technical Parameters:

Feature Power Warranty Tank Volume Voltage Dimension(L*W*H) Applicable Industries Material
Automatic 49KW, 62KW, 63KW, 85KW 1 Year 2500L, 4500L, 7000L, 10000L, 14000L 220V/380V/440V 1700*1100*5300 Manufacturing Plant PP/PE/HDPE/LLDPE


Applications:

Various tanks and other products can be created from different types of materials. Examples include water tanks, oil tanks, military boxes, lampshades, urea tanks, inspection wells, roadblocks, floats, and auto parts. In the aquatic field, kayaks, boats, troughs, and calf barns can also be constructed. Finally, septic tanks can also be produced and used.

The types of products made from various materials depend on the intended use. The types of materials used also vary, depending on the nature of the item. Several different methods are often used in the construction of these items, such as molds and rotational molding.

Each and every product can serve an important purpose and make a difference in everyday life. For example, water tanks and oil tanks are used to store large amounts of liquids for storage and later use. Also, military boxes are used to protect valuable items in hostile environments. Finally, septic tanks are used to treat wastewater for reuse.



Customization:

Bi Axial Rotomoulding Machine
  • Brand Name: Yingchuang
  • Place of Origin: Jiangsu, China
  • Certification: CE, ISO9001
  • Minimum Order Quantity: 1 Acre/Acres
  • Packaging Details: Wooden box
  • Delivery Time: 30 working days
  • Voltage: 220V/380V/440V
  • Tank Volume: 2500L, 4500L, 7000L, 10000L, 14000L
  • Feature: Automatic
  • Dimension(L*W*H): 1700*1100*5300
  • Power: 49KW, 62KW, 63KW, 85KW

Keywords:

  • Rotational Molding Equipment
  • Rotary Moulding Machine
  • Rotary Moulding Machine for Sale


Packing and Shipping:

Packaging and Shipping for Bi Axial Rotomoulding Machine:

The Bi Axial Rotomoulding Machine will be shipped in a wooden crate or container with the following measures:

  • Length: 4 meters
  • Width: 2 meters
  • Height: 2 meters

The crate or container will be filled with foam and all the edges of the crate or container will be protected by foam or plastic wrapping.

The Bi Axial Rotomoulding Machine will be fixed firmly with screws and bolts inside the crate or container. The package will be sealed with plastic tapes.
