Automatic Shuttle Rotomolding Machinery With Max Mold Size 2000*1500*1000mm

Automatic Shuttle Rotomolding Machinery With Max Mold Size 2000*1500*1000mm

Automatic Shuttle Rotomolding Machinery

40kw Shuttle Rotomolding Machinery

1000mm Rotomolding Machine

Place of Origin:

CHANGZHOU

Brand Name:

YINGCHUANG

Certification:

CE, ISO9001

Contact Us

Request A Quote
Product Details
Max Mold Size:
2000*1500*1000mm
Cooling Station:
1
Max Product Volume:
50000L
Total Power:
40kw
Carriage:
2
Rotating Speed:
0-3rpm
Control System:
PLC
Max Product Weight:
500kg
Clamping Force:
200KN
Clamping Stroke:
1000mm
Heating Method:
Electric Heating
Heating Zone:
4 Zones
Power:
7.5KW
Power Supply:
Electric
Product Name:
Shuttle Rotomolding Machine
Rotating Angle:
360°
Size:
3000*3000*3000mm
Temperature Control:
PID
Temperature Range:
0-400℃
Type:
Rotomolding Machine
Voltage:
380V
Weight:
3000kg
Product Description

Product Description:

Our Shuttle machine is an excellent choice for creating larger products. It is an effective machine to use for creating different order in the same time, for example, when the moulds need to be adjusted during production, or if the thickness of two arms differs, or due to the shape difference.

The Shuttle machine has a wide range of applications including Water tank, Oil Tank, Military Box, Lampshade, Urea Tank, Inspection Well, Roadblocks, Float, Auto Parts, Kayak, Boat, Trough, Calf Barn, and Septic Tank.

The machine offers three different types of work arms – Straight arm, L style offset arm or C style offset arm. Also, three types of heating methods are available, natural gas, liquefied gas or diesel oil.

The insulation heating chamber is patented and can aid in energy-saving by reducing energy consumption. Besides, each work-arm can operate independently, so production efficiency is at the highest.

Security is ensured through the interlock function and real-time monitoring of the temperature of the heating chamber, to maintain quality control. Various functions are also offered to make the machine operate efficiently, namely –Process formula can be stored for easy production management; Siemens fully automatic PLC and multiple functions Touch screen; Auto inspection of breakdowns.

In addition, the machine uses Remote fault diagnosis is available.

Automatic Shuttle Rotomolding Machinery With Max Mold Size 2000*1500*1000mm 0

Features:

  • Rotational Molding Equipment: Shuttle Rotomolding Machine
  • Operation Mode: Automatic
  • Max Mold Weight: 1000kg
  • Cooling Station: 1
  • Cycle Time: 15-30min
  • Max Product Volume: 50000L


Technical Parameters:

Attribute Value
Operation Mode Automatic
Cooling Station 1
Carriage 2
Rotating Speed 1-8rpm
PLC Siemens
Max Product Weight 500kg
Control System PLC
Product Name Shuttle Rotomolding Machine
Max Product Volume 50000L
Burner Capacity 500000 Kcar


Applications:

YINGCHUANG Shuttle Rotomolding Machine is an advanced rotational molding equipment with a maximum product volume of 50000L and a maximum mold weight of 1000kg, manufactured in CHANGZHOU and fully compliant with CE and ISO9001 certifications. This automatic rotary moulding machine is equipped with a PLC control system that guarantees maximum operation efficiency with minimum human intervention. We are able to deliver YINGCHUANG Shuttle Rotomolding Machines within 30-60 work days, with a supply capacity of 3-5 machines per month.

Rotational Molding Equipment is a widely used and cost-effective method of producing plastic parts by the melting of plastic powder and its rotation in a closed mold. YINGCHUANG Shuttle Rotomolding Machine is a great choice for industrial applications, as it provides high-quality parts with greater stability and uniform thickness. It is also highly adaptable to various shapes and sizes, giving you the flexibility to create a variety of plastic products.

If you are looking for a reliable and efficient rotary moulding machine, YINGCHUANG Shuttle Rotomolding Machine is the perfect choice for your industrial needs. Our machine is designed to provide excellent performance with the highest quality, and it is easy to operate and maintain. With YINGCHUANG Shuttle Rotomolding Machine, you can rest assured that you're getting the best possible value for your money.



Customization:

Shuttle Rotomolding Machine Customized Services

Brand Name: YINGCHUANG

Place of Origin: CHANGZHOU

Certification: CE, ISO9001

Delivery Time: 30--60 work days

Supply Ability: 3-5 machines per month

Max Product Weight: 500kg

Carriage: 2

Max Mold Size: 2000*1500*1000mm

Product Name: Shuttle Rotomolding Machine

Total Power: 40kw

YINGCHUANG provides customized services for the Shuttle Rotomolding Machine, which is a kind of Rotomolding Machinery or Rotary Moulding Machine. With CE and ISO9001 Certification, the max product weight is 500kg and the max mold size is 2000*1500*1000mm. 30-60 work days are needed for delivery and 3-5 machines can be supplied per month. The total power is 40kw and the carriage is 2.



FAQ:

  • Q: What is the brand name of this Shuttle Rotomolding Machine?
    A: The brand name of this Shuttle Rotomolding Machine is YINGCHUANG.
  • Q: Where is this Shuttle Rotomolding Machine manufactured?
    A: This Shuttle Rotomolding Machine is manufactured in CHANGZHOU.
  • Q: What certifications does this Shuttle Rotomolding Machine have?
    A: This Shuttle Rotomolding Machine has CE and ISO9001 certifications.
  • Q: How long will it take to deliver the Shuttle Rotomolding Machine?
    A: It will take 30--60 work days to deliver the Shuttle Rotomolding Machine.
  • Q: What is the supply ability for this Shuttle Rotomolding Machine?
    A: The supply ability for this Shuttle Rotomolding Machine is 3-5 machines per month.
